Frame
frame
C:68X® Monocoque Advanced Twin Mold Technology, FSP 4-Link, Boost 148, UDH™
size
29: S, M, L, XL
Suspension
Suspension fork
Fox 34 SC Float Performance, 2-Position Remote, Tapered, 15x110mm, 110mm
shock
Fox Float SL Performance Elite, 190x40mm, 2-Position Remote
shock hardware
Front: 26x8mm, Rear: 30x8mm
Drivetrain & brakes
brake system
Shimano XT BR-M8100, Hydr. Disc Brake (180/160)
rear derailleur
Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed
shifters
Shimano XT SL-M8100-IR, Direct Attach
bottom bracket
Shimano BB-MT500PA, 92mm Pressfit
crankset
Shimano XT FC-M8100, 32T, Boost
cassette
Shimano SLX CS-M7100, 10-51T
chain
Shimano CN-M6100
Cockpit
headset
ACROS Integrated, Top 1 1/8″, Bottom 1 1/2″, Fiber Inserts for Angle Adjustment
Stem
Newmen Evolution SL 318.2, 31.8mm
handlebar
Newmen Advanced 318.0, Carbon, 740mm
grips
ACID Disrupt, Soft Compound
Wheels
wheelset
Newmen Beskar 30 light/light, 28/28 Spokes, 15x110mm/12x148mm, Tubeless Ready
front tyre
Schwalbe Racing Ray, Super Race, Addix Speed, Kevlar, 2.35
rear tyre
Schwalbe Racing Ralph, Super Race, Addix Speed, Kevlar, 2.35
Finishing kit
saddle
ACID Nuance SLT X Carbon
seat post
Fox Transfer Performance Elite 30.9mm
Product information
colour
blackline
weight
11,5 kg
